The Problem: 11 Datasets, Zero Integration

Uruguay's Interior Ministry publishes open data on crime, domestic violence, sexual offenses, femicides, the prison system, and police infrastructure. It's a remarkable level of transparency for a country of 3.5 million.

But the data arrives as isolated datasets:

• 6 tabular datasets: 2.4 million crime records spanning 2003-2025, each with different schemas, column naming conventions, and department spellings.
• 5 geographic layers: Police precincts, stations, gender violence centers, fire stations, headquarters — in KML and SHP formats with no shared identifiers.

This project builds the integration layer — and then goes further. Instead of stopping at a clean warehouse, I added a neuro-symbolic analysis layer: formal verification with Z3, entity linking with an LLM, and crime prediction combining Graph Neural Networks with domain knowledge encoded as symbolic rules.

Architecture: From CSVs to Predictions

 Data Sources (Interior Ministry)
 ┌──────────────────┐    ┌──────────────────┐
 │  6 Tabular CSVs  │    │  5 Geographic    │
 │  (CKAN API)      │    │  (KML / SHP)     │
 └────────┬─────────┘    └────────┬─────────┘
          │                       │
          ▼                       ▼
 ┌──────────────────────────────────────────────┐
 │          Bruin Pipeline (local)              │
 │  ingest → transform → verify → graph         │
 └──────────────────┬───────────────────────────┘
                    │
                    ▼
 ┌──────────────────────────────────────────────┐
 │        GCS Data Lake (Parquet)               │
 │  13 processed files + knowledge graph        │
 │  627K triples / 125K nodes                   │
 └──────────────────┬───────────────────────────┘
                    │
          ┌─────────┴──────────┐
          ▼                    ▼
 ┌─────────────────┐  ┌────────────────────────┐
 │  BigQuery       │  │  Google Colab (A100)   │
 │  External Tables│  │  NB04: Z3 verification │
 └─────────────────┘  │  NB05: Qwen Text2SQL  │
                      │  NB06: GNN + symbolic  │
                      └────────────────────────┘

The first half is classic data engineering — ingest, transform, load. The second half is where it gets interesting.

The Department Problem: 19 Names, 47 Spellings

Before any analysis, I had to solve something embarrassingly basic: departments are spelled differently across datasets.

Dataset A: "MALDONADO"
Dataset B: "MALDONDADO"     ← typo
Dataset C: "PAYSANDÚ"      ← accent
Dataset D: "Tacuarembo"    ← lowercase
Dataset E: "RÍO NEGRO"     ← accent
Dataset F: "SAN JOSÉ"      ← accent

This isn't a minor issue. If "PAYSANDÚ" and "PAYSANDU" don't match, your knowledge graph has two separate nodes for the same department. Your GNN has phantom departments. Your cross-dataset joins silently drop rows.

The fix was a normalization function applied across all 7 transform scripts:

DEPARTMENT_FIXES = {
    "MALDONDADO": "MALDONADO",
    "TACUEREMBO": "TACUAREMBO",
    "PAYSANDÚ": "PAYSANDU",
    "RÍO NEGRO": "RIO NEGRO",
    "SAN JOSÉ": "SAN JOSE",
    "TACUAREMBÓ": "TACUAREMBO",
}

def normalize_department(name: str) -> str:
    upper = name.strip().upper()
    return DEPARTMENT_FIXES.get(upper, upper)

Applied once in the shared library, called from every transform. After normalization: 19 departments, 19 spellings, zero duplicates.

Knowledge Graph: 627,000 Triples

With normalized departments, I could build a proper knowledge graph. Each crime record, each police station, each geographic boundary becomes an RDF triple:

crime:EVT_123456 a crime:CrimeEvent ;
    crime:hasType "HURTO" ;
    crime:occurredIn dept:MONTEVIDEO ;
    crime:inYear 2023 ;
    crime:inMonth "MARZO" .

dept:MONTEVIDEO a geo:Department ;
    geo:hasStation station:COMISARIA_1 ;
    geo:hasCEVDG cevdg:MONTEVIDEO_1 .

The result: 627,376 triples connecting 125,535 nodes across all 11 datasets. Now I can run SPARQL queries that no single dataset could answer:

# Which departments have high DV rates but no gender violence center?
SELECT ?dept (COUNT(?event) as ?dv_count)
WHERE {
    ?event a crime:DomesticViolence ;
           crime:occurredIn ?dept .
    FILTER NOT EXISTS { ?dept geo:hasCEVDG ?center }
}
GROUP BY ?dept ORDER BY DESC(?dv_count)

Formal Verification With Z3: Proving Your Data Isn't Broken

Most data quality checks are assertions: "this column should not be null." But assertions only tell you that a specific row failed — they don't tell you whether the schema itself is coherent.

Z3 is a theorem prover. Instead of checking individual rows, I asked it: can any valid row exist under these constraints?

from z3 import *

ano = Int('ano')
depto = String('depto')

# Schema constraints
constraints = And(
    ano >= 2003, ano <= 2025,
    Or(*[depto == StringVal(d) for d in VALID_DEPARTMENTS]),
)

solver = Solver()
solver.add(constraints)

if solver.check() == sat:
    print("SAT — schema is consistent")
    model = solver.model()
    print(f"Example valid row: year={model[ano]}, dept={model[depto]}")

Three verification phases:

1. Spec consistency: Can any valid row exist? (SAT = yes, the spec isn't contradictory)
2. Data boundary validation: Do actual min/max values fit within the spec?
3. Cross-dataset consistency: Do year ranges overlap where expected?

LLM-Powered Text2SQL: Asking Questions in Plain Language

Notebook 05 uses Qwen2.5-7B-Instruct (4-bit quantized on A100) for two tasks:

1. Entity Linking

2. Text2SQL

Q: "How many crimes were reported in Montevideo in 2023?"
→ SELECT COUNT(*) FROM delitos WHERE depto = 'MONTEVIDEO' AND ano = 2023
→ Result: 94,001

The key lesson: prompt engineering matters more than model size. My first version used DESCRIBE delitos output as schema context. The model generated wrong column references (YEAR(fecha) instead of ano, barrio_montevideo for department filtering).

The fix was including sample values and explicit column hints:

schema_lines = []
for col_name in df.columns:
    uniques = df[col_name].drop_nulls().unique().sort()
    if len(uniques) <= 10:
        sample = uniques.to_list()
    else:
        sample = uniques.head(5).to_list() + ["..."]
    schema_lines.append(f"  {col_name} ({dtype}): {sample}")

With sample values in the prompt, the model generates correct SQL on the first try. No fine-tuning needed.

Model Selection: Why Not a Reasoning Model?

I initially planned to use QwQ-32B (a reasoning model) for semantic evaluation. Bad idea. Taxonomy matching is classification, not deep reasoning. QwQ generates massive <think> blocks — 10+ minutes for a 931-character prompt, even in 4-bit quantization. I switched back to Qwen2.5-7B and the same task completed in seconds.

Lesson: match model capability to task complexity. A reasoning model for a classification task is like using a crane to move a chair.

GNN Crime Prediction: Where Neural Meets Symbolic

This is the core of the neuro-symbolic approach. The goal: predict next year's crime counts per department.

The Graph

Uruguay has 19 departments. I dissolved 280 police precinct polygons into department boundaries and built an adjacency graph: two departments are neighbors if they share a border.

Adjacency graph: 19 nodes, 37 edges
Average degree: 3.9

MONTEVIDEO neighbors: [CANELONES, SAN JOSE]
CANELONES neighbors: [FLORIDA, LAVALLEJA, MALDONADO, MONTEVIDEO, SAN JOSE]
SALTO neighbors: [ARTIGAS, PAYSANDU, RIVERA, TACUAREMBO]

The Neural Component

A 2-layer Graph Convolutional Network (GCN) with 1,281 parameters. Input: crime counts per type per department for year T. Output: predicted total crimes for year T+1.

Training uses temporal split — no data leakage:

• Train: 11 year-pairs (2013→2014 through 2023→2024)
• Validation: 2024→2025

The Symbolic Component

Five rules derived from the actual 2.4M crime records, not invented:

Fusion

The final prediction multiplies neural and symbolic:

prediction = neural_pred × seasonal × hour × urban × escalation

This decomposition is the entire point. A stakeholder can ask "why is Montevideo predicted high in January at 20h?" and get: "the GNN learned spatial patterns (Montevideo concentrates crime), summer increases hurto by 10%, evening hours add 14%, and the urban factor is 1.2x."

Results and Class Imbalance

VALIDATION SCORES (2024 → 2025)
  MAE:       1,735 crimes/dept
  RMSE:      2,853 crimes/dept
  MAPE:       41.7%
  R²:        0.9738

R² looks great. MAPE tells the real story. The model predicts well for departments with enough data:

The high R² is driven by Montevideo's scale dominating the variance. MAPE is the honest metric: useful for high-volume departments, limited for rural ones.

Why Neuro-Symbolic?

A pure neural model would be a black box. A pure rule-based system can't learn spatial diffusion patterns from data. The combination gives you:

1. Interpretability: Every prediction decomposes into explainable factors. Auditable for government stakeholders.
2. Data efficiency: Symbolic rules encode domain knowledge that would require decades of data for a neural model to learn independently.
3. Scenario planning: Change the month, hour, or DV threshold and immediately see the impact. Impossible with a black-box model.

Lessons

1. Normalize before everything

Department normalization was a 30-line function that unblocked the entire downstream pipeline. Without it, the knowledge graph had phantom nodes, the GNN had misaligned features, and cross-dataset joins silently dropped rows.

2. R² lies when your data has class imbalance

With one department (Montevideo) having 100x more crime than the smallest (Flores), R² will be high even if the model just predicts the mean. Always check MAPE and per-class metrics.

3. Match model complexity to task complexity

QwQ-32B for taxonomy matching: 10+ minutes, massive <think> blocks, same accuracy as Qwen2.5-7B in 3 seconds. A reasoning model for a classification task burns GPU time for zero benefit.

4. Symbolic rules need to be data-driven

My first version had made-up seasonal factors. The actual data showed abigeato peaks in winter — the opposite of most crime types. You can't invent domain knowledge; you have to derive it from data.

5. Small graphs over-smooth

A GCN on 19 nodes with average degree 3.9 will propagate information across the entire graph in 2 hops. All small departments converge to the same prediction. This is a known GCN limitation, not a bug — but it means the architecture is better suited for denser graphs (e.g., 280 precincts).

Stack

What's Next?

• Temporal GNN: Replace static GCN with T-GCN or DCRNN to learn time-varying patterns directly instead of relying on year-pair snapshots.
• Real DV integration: Pull actual domestic violence rates from the VD dataset instead of simulating them for the escalation rule.
• Precinct-level graph: With 280 seccionales instead of 19 departments, the GCN would have enough nodes to avoid over-smoothing.
• Backtesting: Proper temporal cross-validation instead of a single train/val split.
